Engel injection machines 160 ton-220 ton; 2k injection service available with an extra barrel
All tooling, moulding, packaging, and assembly are completed on our 193,750 sq. ft (18,000 sq m) campus in Shenzhen, the innovation center of China.
Item | Description | Brand | Country of Origin |
Precision (mm) |
Quantity | Remarks |
1 | High Speed 5-Axis CNC |
Breton
MATRIX |
Italy | 0.002 | 1 | Axis
Travels: 2500 x 2000 x 800 A-Axis:-105°/+105° C-Axis:19 rpm Table Size: 3000×2000 Max. RPM: 28000r/ min |
OPS Ingersoll |
Germany | 0.002 | 1 | Axis
Travels: 650 x 550 x 500 A-Axis:120°/+60° C-Axis:60 rpm Table Size: 850×700 Max. RPM: 42,000r/ min |
||
OPS Ingersoll |
Germany | 0.002 | 1 | Axis
Travels: 550 x 400 x 400 B-Axis:120°/+60° C-Axis:60 rpm Table Size: 650×500 Max. RPM: 42,000r/ min |
||
2 | High Speed CNC |
MORI SEIKI |
Japan | 0.002 | 1 | Axis
Travels: 600 x 400 x 400 Table Size: 700×450 Max. RPM: 24,000r/ min |
FANUC | Japan | 0.002 | 1 | Axis
Travels: 500 x 400 x 330 Table Size: 650×400 Max. RPM: 24,000r/ min |
||
3 | Medium Speed CNC |
YCM DCV2012A |
Taiwan | 0.005 | 1 | Axis
Travels: 2000x1200x600 Table Size: 2000 x 1100 Max. RPM: 20000r/ min |
YCM 125A |
Taiwan | 0.005 | 1 | Axis
Travels: 1270*520*540 Table Size: 1350*520 Max. RPM: 15,000r/ min |
||
YCM 85A |
Taiwan | 0.005 | 1 | Axis
Travels: 850*520*540 Table Size: 1000*520 Max. RPM: 15,000r/ min |
||
4 | CNC | YCM MV106A |
Taiwan | 0.01 | 1 | Axis
Travels: 1020*600*600 Table Size: 1120 * 600 Max. RPM: 8,000r/ min |
YCM 158B |
Taiwan | 0.02 | 1 | Axis
Travels: 1500*860*750 Table Size: 1700 * 860 Max. RPM: 8,000r/ min |
||
YCM 2110B |
Taiwan | 0.02 | 1 | Axis
Travels: 2100*1020*762 Table Size: 2300*1020 Max. RPM: 8,000r/ min |
||
H-850L | China | / | 2 | Axis Travels: 800X500X450 | ||
Pioneer 650 |
Taiwan | / | 3 | Axis Travels: 600X500X450 | ||
YCM 102A |
Taiwan | / | 2 | Axis Travels: 1020X520X540 | ||
H-1580L | China | / | 1 | Axis Travels: 1500X800X700 | ||
5 | Precision EDM |
CHARMILLES | Switzerland | 0.002 | 2 | Electrodes:54
pcs Table Size:500*400 Axis Travels:350*300*280 Surface finish: 0.3 μm Ra |
CHARMILLES | Switzerland | 0.002 | 1 | Electrodes:4
pcs Table Size:500*400 Axis Travels:350*300*280 Surface finish: 0.3 μm Ra |
||
Makino | Japan | 0.002 | 1 | Table Size:600 × 450 Axis Travels: 450 x 300 x 320 Surface finish:0.5 μmRa | ||
6 | EDM | Wintop DF-435 |
Taiwan | 0.005 | 1 | Table Size: 500 × 300 |
Mirrordick A30 |
China | 0.005 | 1 | Table size: 600×400 | ||
Mirrordick Double Head |
China | 0.005 | 1 | Table Size: 2500x1500 | ||
Mirrordick Double Head |
China | 0.005 | 1 | Table Size: 1500x800 | ||
7 | Precision Wire Cutting Machine |
Agie Charmilles CUT C350 |
Switzerland | 0.002 | 2 | Max.
machining size:820 x 680 x 250 Max. work piece weight: 400kg Travels(X*Y*Z): 350 x 250 x 250 |
Agie Charmilles CUT C600 |
Switzerland | 0.002 | 2 | Max.
machining size: 1030X800X350 Max. work piece weight: 1000kg Travels(X*Y*Z): 600*400*350 |
||
Agie Charmilles CA20U |
Switzerland | 0.002 | 1 | Max.
machining size:900×680×250 Max. work piece weight: 400kg Travels(X*Y*Z): 350 x 250 x 250 |
||
8 | Milling Machine |
DEFOND | Taiwan | 0.05 | 3 | |
9 | Grinding Machine |
HYFAIR | China | 0.005 | 5 | |
10 | Lathe Machine |
Mazak QTE 200MYL |
Japan | 0.005 | 1 | Axis
Travels: 215*100*605/1155 Max. RPM: 6000r/ min Milling/drilling capability: Φ20 Tapping capability: M20 × 2.5 |
Arrow | China | 0.02 | 1 | |||
11 | Gun Drilling Machine |
ACCURATE | HongKong | 0.02 | 1 | Axis Travels(X*Y): 1000 x 1000 Max. machining diameter: 2-30 Max. machining depth: 1000 |
0.02 | 1 | Axis Travels(X*Y): 800 x 700 Max. machining diameter: 2-30 Max. machining depth8: 700 | ||||
12 | Movable Universal Radial Drilling Machine |
Zhongjie | China | 0.05 | 1 | Max.machining diameter:50 |
13 | Fitting Machine Horizontal |
Nice NCW-70 |
China | / | 1 | Max
Spotting Force: 70T Max Lifting Force: 27T Die Open Space: 1000 Size of Working Bench: 600x600 |
Nice NCW-150 |
China | / | 1 | Max
Spotting Force: 150T Max Lifting Force: 50T Die Open Space: 1400 Size of Working Bench: 1500x1100 |
||
Nice NCW-300 |
China | / | 1 | Max
Spotting Force: 300T Max Lifting Force: 60T Die Open Space: 2100 Size of Working Bench: 2500x1800 |
Item | Description | Brand | Country of Origin | Specification | Quantity |
1 | CMM | Hexagon Serein | China | 800*1000*600 | 1 |
2 | CMM | Hexagon Serein | China | 1000*1500*800 | 1 |
3 | CNC Image Measuring Instrument | Hexagon Serein | China | 200*300 | 1 |
4 | Height Measuring Instrument | Hexagon Serein | China | 1000 | 1 |
5 | Projector | VMS300 | Taiwan | 200×300 | 1 |
6 | Test Projector | Wanhao | China | 150*200 | 1 |
7 | Rockwell Hardness Tester | / | China | HR-150A | 1 |
8 | Hardness Tester | HR-150A | China | 29.5~62.5HRC | 1 |
9 | Portable Hardness Tester | / | China | / | 2 |
10 | Calipers | Mitutoyo | Japan | / | 40 |
11 | Micrometer Caliper | Mitutoyo | Japan | / | 10 |
12 | Pin Gauge | / | China | 0.1~20 | 1 |
13 | Block Gauge | / | China | 0.05~100 | 3 |
14 | Plug Gage | / | China | 0.5~3.0 | 1 |
15 | Block Gauge | / | China | 1.005~100 | 1 |
16 | Height Gauge | Jingfeng | China | 0~300 | 1 |
17 | Mechanical Square | Jingfeng | China | 150*200 | 1 |
18 | Colorimeter | Konica Minolta | Japan | / | 1 |
18 | Surftest | Mitutoyo | Japan | SJ-210 | 1 |
Workshop | Item | Clamp Force | Brand | Country of Origin | drive system | Inj. Volume (g) |
Mold thickness (mm) |
Screw Dia. (mm) |
Tie-bar (mm) |
Radius | Daylight | Locating Ring | Remark | |
Cleanroom class ISO 8 (100,000) |
1 | 90T | Welltec | China | hydraulic | 121 | 150-360 | 32 | 360*360 | 45 | 360 | 120 | 1K, horizontal | |
2 | 110T | JSW | Japan | electric | 90 | 200-400 | 32 | 460*460 | 45 | 350 | 120 | 1K, horizontal | ||
3 | 320T | Welltec | China | electric | 594 | 250-660 | 55 | 660*660 | 45 | 615 | 160 | 1K, horizontal | ||
4 | 160T | Engel | Austria | hydraulic | 260 | 150-450 | 30 | 750*750 | 30 | 500 | 120 | 1K, horizontal | ||
Conventional Room |
5 | 30T | Sumitomo | Japan | hydraulic | 30 | 80-180 | 15 | 180*180 | 45 | 200 | 100 | 1K, horizontal | |
6 | 90T | Haitian | China | hydraulic | 121 | 150-360 | 32 | 360*360 | 45 | 320 | 120 | 1K, horizontal | ||
7 | 110T | JSW | Japan | electric | 90 | 200-400 | 32 | 460*460 | 45 | 350 | 120 | 1K, horizontal | ||
8 | 160T | Welltec | China | hydraulic | 298 | 150-460 | 45 | 460*460 | 45 | 340 | 160 | 1K, horizontal | ||
9 | 160T | Welltec | China | hydraulic | 298 | 150-460 | 45 | 460*460 | 45 | 340 | 160 | 1K, horizontal | ||
10 | 160T | Welltec | China | hydraulic | 298 | 150-460 | 45 | 460*460 | 45 | 340 | 160 | 1K, horizontal | ||
11 | 160T | Welltec | China | hydraulic | 298 | 150-460 | 45 | 460*460 | 45 | 340 | 160 | 1K, horizontal | ||
12 | 200T | Haitian | China | hydraulic | 334 | 200-500 | 45 | 530*530 | 45 | 490 | 120 | 1K, horizontal | ||
13 | 200T | Haitian | China | hydraulic | 334 | 200-500 | 45 | 530*530 | 45 | 470 | 120 | 1K, horizontal | ||
14 | 220T | Nissei | Japan | hydraulic | 228 | 670-850 | 45 | / | 40 | 920 | / | 1K, vertical | ||
15 | 230T | Toshiba | Japan | electric | 260 | 200-550 | 45 | 610*610 | 45 | 550 | 160 | 1K, horizontal | ||
16 | 260T | Welltec | China | hydraulic | 543 | 200-580 | 55 | 680*680 | 45 | 455 | 160 | 1K, horizontal | ||
17 | 260T | Welltec | China | hydraulic | 543 | 200-580 | 55 | 680*680 | 45 | 455 | 160 | 1K, horizontal | ||
18 | 300T | Changrong | Taiwan | hydraulic | 700 | 300-820 | 50 | 550*550 | 45 | 600 | 160 | 1K, horizontal | ||
19 | 380T | Welltec | China | hydraulic | 835 | 250-740 | 60 | 740*740 | 45 | 710 | 160 | 1K, horizontal | ||
20 | 450T | Welltec | China | hydraulic | 1530 | 300-820 | 80 | 780*780 | 45 | 740 | 160 | 1K, horizontal | ||
21 | 1000T | Welltec | China | hydraulic | 4191 | 450-1150 | 100 | 1100*1100 | 45 | 1150 | 160 | 2K, horizontal | ||
365 | / | 45 | 45 | |||||||||||
22 | 220T | Engel | Austria | hydraulic | 280 | 200-500 | 50 | 800*800 | 30 | 650 | 160 | 2K, horizontal | ||
80 | / | 26 | 30 | |||||||||||
23 | 450T | Welltec | China | hydraulic | 1050 | 300-820 | 80 | 780*780 | 45 | 615 | 160 | 3K, horizontal | ||
60 | 300-820 | 26 | 45 | |||||||||||
35 | 300-820 | 18 | 45 |
Engel injection machines 160 ton-220 ton; 2k injection service available with an extra barrel
3K injection machine by Welltec 450 ton.
2K injection machine by Welltec 1000T ton.
Vertical injection machine by Nissei 220T ton
